Here’s a conceptual diagram layout for a Landslide Early Warning System based on

Here’s a conceptual diagram layout for a Landslide Early Warning System based on your description: **1. Central Processing Unit (CPU)** - **Location**: Centralized control room or on-site station. - **Description**: Computer/server rack with data processing software and user interface. **2. Sensors** - **Seismometers & Geophones** - **Location**: Multiple points around the landslide-prone area. - **Description**: Cylindrical/rectangular devices with cables leading to CPU. - **Inclinometers** - **Location**: Embedded in the slope or on at-risk structures. - **Description**: Tubular devices embedded vertically or mounted. - **Piezometers** - **Location**: Boreholes in the slope. - **Description**: Small cylindrical devices in drilled holes. - **Accelerometers** - **Location**: Mounted on the ground or critical structures. - **Description**: Compact, box-shaped devices. **3. Communication Infrastructure** - **Data Hubs** - **Location**: Strategically placed for data collection. - **Description**: Enclosures/boxes with antennas or wired connections. - **Networking** - **Location**: Between sensors, data hubs, and CPU. - **Description**: Includes wireless antennas, fiber optic cables, satellite dishes. **4. User Interface (UI)** - **Location**: Accessed from CPU control room or remotely. - **Description**: Displays real-time data, charts, and alerts on computers or tablets. **5. Alert System** - **Physical Alerts** - **Location**: Visible in the affected area. - **Description**: Sirens, flashing lights, or digital message boards. - **Digital Alerts** - **Location**: Sent to mobile phones, email, or other devices. - **Description**: Automated messages or notifications. **6. Power Supply** - **Location**: Near sensors and CPU. - **Description**: Solar panels, batteries, or electrical grid connections. **Diagram Layout Example:** - **Top-Down View
