Finally, You are asked to use the Proteus simulator to simulate the circuit in Figure 1, considering the following component values: • C1 = 47 µf • C1 = 47 µf • R1 = 100 KΩ • R2 = 80 KΩ • T1 = BC547 • T2 = TIP39 Once the amplifier is configured in the simulator, place a 1 KHz sinusoidal signal as input, with an amplitude of 0.1 Vpp and display the output. In this regard: b. Attach a screenshot where the assembled circuit can be seen, the input and output signal. IF YOU NEED FIGURE 1 IT'S AN AUDIO AMPLIFIER CIRCUIT I NEED IT TO BE AN IMAGE DIRECTLY FROM PROTEUS
