Here’s a conceptual diagram layout for a Landslide Early Warning System based on

Here’s a conceptual diagram layout for a Landslide Early Warning System based on your description:

**1. Central Processing Unit (CPU)**
- **Location**: Centralized control room or on-site station.
- **Description**: Computer/server rack with data processing software and user interface.

**2. Sensors**
- **Seismometers & Geophones**
- **Location**: Multiple points around the landslide-prone area.
- **Description**: Cylindrical/rectangular devices with cables leading to CPU.
- **Inclinometers**
- **Location**: Embedded in the slope or on at-risk structures.
- **Description**: Tubular devices embedded vertically or mounted.
- **Piezometers**
- **Location**: Boreholes in the slope.
- **Description**: Small cylindrical devices in drilled holes.
- **Accelerometers**
- **Location**: Mounted on the ground or critical structures.
- **Description**: Compact, box-shaped devices.

**3. Communication Infrastructure**
- **Data Hubs**
- **Location**: Strategically placed for data collection.
- **Description**: Enclosures/boxes with antennas or wired connections.
- **Networking**
- **Location**: Between sensors, data hubs, and CPU.
- **Description**: Includes wireless antennas, fiber optic cables, satellite dishes.

**4. User Interface (UI)**
- **Location**: Accessed from CPU control room or remotely.
- **Description**: Displays real-time data, charts, and alerts on computers or tablets.

**5. Alert System**
- **Physical Alerts**
- **Location**: Visible in the affected area.
- **Description**: Sirens, flashing lights, or digital message boards.
- **Digital Alerts**
- **Location**: Sent to mobile phones, email, or other devices.
- **Description**: Automated messages or notifications.

**6. Power Supply**
- **Location**: Near sensors and CPU.
- **Description**: Solar panels, batteries, or electrical grid connections.

**Diagram Layout Example:**
- **Top-Down View
