make a sketch of this project
**Aluminum Can Press**
#### **Purpose:**
The aluminum can press is designed for compressing cans
,
reducing its volume and facilitating storage and recycling
.
It is ideal for homes
,
schools
,
and small businesses that want to contribute to the recycling process
.
#### **Materials Needed:**
- Metal profiles (square tubes or angles)
- Steel plates for the compression plate and base - Long metal lever (it could be an iron bar)
- Return spring (optional)
- High strength bolts and nuts - Electrodes and welding machine - Cutting tools (grinder
,
band saw)
- Drill with suitable bits
#### **walkthrough:**
1
.
**Planning and Design:**
- Draw the project
,
defining the dimensions of the structure according to the size of the cans to be compacted
.
The standard height for a 350ml can is about 12cm
.
- Determine the height of the lever to ensure that the force applied is sufficient to compress the can
.
2
.
**Construction of the Structure:**
- Cut the metal profiles to form the base and vertical structure
.
The base must be robust enough to withstand the pressure applied
..
- Weld the profiles forming a "L"
,
with the horizontal base and the vertical structure
.
- Attach side guides to the vertical frame to keep the compression plate aligned
.
3
.
**Compression Plate Manufacturing:**
- Cut a steel plate to the appropriate size for the compression plate
.
It should be slightly smaller than the diameter of the can to ensure the can is compressed evenly
..
- Connect the compression plate to the metal lever through a pivot point
,
allowing the lever to move the plate down
.
4
.
**Lever Installation:**
- Attach the lever to the top of the vertical frame
.
The lever must be long enough so that the operator can apply significant force without much effort
..
- If you wish
